| Weight | N/A |
|---|---|
| Model | FC75-2UCB00-SG, 5200-C00075G |
Optical & Performance
- Sensor1280 (H) x 960 (V) pixels
- Aiming Element610nm, Green LED
- IlluminationWhite LED
- Ambient LightWorks in any lighting conditions from 0 to 100,000 lux
- Scan Rate60 fps
- Pitch Angle Sensor±60°
- Roll Angle360°
- Field of ViewHorizontal – 44.5°, Vertical – 33.5°
- Printing Contrast Scale20% Minimum
- Depth of FieldSYMBOLOGY: Near // Far
5.0 mil Code 39: 2.4 in. (6.1 cm) // 9.5 in. (24.1 cm)
5.0 mil Code 128: 2.8 in. (7.1 cm) // 9.0 in. (22.9 cm)
6.67 mil PDF417: 2.4 in. (6.1 cm) // 8.0 in. (20.3 cm)
10 mil Datamatrix: 2.9 in. (7.4 cm) // 8.5 in. (21.6 cm)
100% UPCA: 1.8 in. (4.6 cm) // 19.5 in. (49.5 cm)
15 mil QR: 1.2 in. (3.0 cm) // 11.5 in. (29.2 cm)
20 mil QR: 1.2 in. (3.0 cm) // 14.0 in. (35.6 cm)
Communication
- Host Interface supportedRS232, USB (HID KBW or Virtual comport)
Mechanical
- Dimension56 mm x 69 mm x 27.7 mm
- Weight85g (scanner only)
Symbologies
- 1D BarcodesEAN/UPC, UCC/EAN128, ISBN, ISBT, Code 39, Code 93/93i, Code 128, Interleaved, Standard 2 of 5, Codabar, MSI, GS1 DataBar
- 2D BarcodesData Matrix, PDF 417, Micro PDF 417, Maxicode, QR code, Aztec, MicroQR code
Electrical
- Operation VoltageDC +5V±5%
- Current Consumption330mA
Environmental
- ESD Protection±8KV air discharge, ±4KV conductive discharge
- Mechanical Shock2000G, 0.85ms, half sinus, 3axes
- Operating Temperature-20°C to 50°C (-4°F to 122°F)
- Storage Temperature-30°C to 70°C (-22°F to 158°F)
- Relative Humidity5% to 95% (Non-condensing)
- IP RatingIP42
Accessories
- Items■ Power Supply for RS232 Cable (PN# 1010-900008G)
Regulatory Approvals
- Regulatory ApprovalsFCC
Warranty
- Hardware Warranty24 months
- StatementThis product is warranted against defects in workmanship and materials for a period of two years from the date of shipment. Accessories are warranted for three months to one year. Our different regions have varying warranty terms, and offer extended and comprehensive warranties, so please contact your local representative for more information.
